WORLD TOURER

Designed, developed and made in India.

Rs 3,10,000 Onwards

THE OVERVIEW OBERON

Oberon will have all the characteristics of a world tourer that you can load up and do kilometers and kilometers, maintenance free. We did this in co-operation with world’s best in the segment. Selected steel tubes from Columbus Zona with CrMo steel touring fork. This will be a flared drop bar road touring bike with Rohloff Speedhub and Gates Carbon CDX:EXP belt transmission. Got custom-made heavy duty rims from RAD15, a boutique firm in Netherlands. Hy/Road disc brakes from TRP. SP dynamo hubs + 650x50c tyres from Goodyear. Leather seats from Tabor of Portugal and Deda components.

The bike is developed in collaboration with Scolarian. Apart from standard 5 sizes, we can also make fine custom measurements against order. The geometry is developed aiming for relaxed multiple day expedition rides. It is considerably upright as reflected in the stack values. All frames are designed with a mid-low stand over height making the top tube slant with enough inseam clearance. With a longish chain stay length of 453 mm combined with a trail value of 70s, you get a stable bike whether you load front or back or both.



Tyre clearance for both frame and fork is upto 27.5”x2.25” (without fender), 27.5”x2.1” (with fender) and we'll be providing 650x50c tyres.



The price is 3.10 lacs for Oberon, including all racks, stand, fenders, dynamo hub & light.

POSST OBERON Equipment & Geometry Chart



We will take booking now for delivery in March 2024. For details call/message 9840080627.

How it works

TECH SPECS & EQUIPMENT OBERON

CHASSIS

Frame - Select Columbus Steel Tubes

Fork - CrMo Steel Fork

Headset -  Cane Creek ZS44/28.6/30-H8

Spacers - Deda Aluminium Anodized

Rack Carriers - Atran Velo Tour  / Explorer Series

Kick Stand - Atran Velo Rex Center Mount

SEAT

Saddle - Tabor Leather Tour or City

Seat Post - Deda Zero1 Alloy 6061, Dia 27.2

Seat Clamp - Custom Cnc Machined 6061. Ti Bolt

COCKPIT

Handlebar - Deda Gravel 100 RHM 130/75 Flare 12 degree.

Stem - Deda Zero 1 3D Forged, Alloy 6061.

Bar Tapes - Cyclovation Premium Silicone Touch.

Brake Levers - TRP RRL SR

Shifters - Rohloff Twist Shifter.

Lights - SP PL7 Dynamo Hub / DS-4 Light

Bar End Plugs - Posst Custom Cnc Machined Alu 6061

FRAME TUBES

​Head Tube - Columbus Spirit HSS.  Omnicrom 46 mm
Top Tube - Columbus Zona Double Butted 25crmo4
Down Tube - Columbus Zona Double Butted 25crmo4
Seat Tube - Columbus Zona Double Int / Ext Butted 25crmo4
Seat Stay - Columbus Zona S Bend 25crmo4 Seamless
Chain Stay - Columbus Zona Butted Double Bend 25crmo4

DRIVETRAIN

Crank - Gates Carbon Drive S550 CDX 170

Front Sprocket - Gates Carbon Drive 50T CDX

Belt - Gates Carbon Drive 118T CDX

Bottom Bracket - FSA 68MM MegaExo Threaded

Rear Sprocket - Gates Carbon Drive 20T CDX

Gear System - Rohloff Speedhub 500/14 CC DB 36 Hole

Pedals - DMR V-11 Flat

WHEELSET

Wheelset - RAD15 Storm26 650 C26

Wheelhub Front - P PL-7 Dynamo Hub

Thru Axle F- POSST Custom Machined 12-100

Tires - Goodyear Connector Premium TR 650x50

Fenders - Sunnywheel Custom Aluminium.

BRAKES

Brakes Caliper - TRP Hy/Rd Disc

Brakes Rotor F - TRP 180mm Rotor

Brake Rotor R - Rohloff 160 mm Rotor

DATA

Bicycle Weight - 16 Kg  / Size 54
Laden Weight - 180 Kg. Incl rider and kits.

Classification - Class 1 Category.

GEOMETRY OBERON
